Description
Toughpower PF3 series is 80 PLUS Platinum certified and fully compatible with Intel’s ATX 3.0 specifications. Designed with a native PCIe Gen 5 connector, it can power up next-gen technology with one new 12VHPWR cable.
Form Factor ATX 3.0
Edition PF3
Wattage 750 W
Energy Efficiency Certification 80 PLUS Platinum
Max. Efficiency (at 230Vac)
Cooling Fan
Fans 1 x 120mm
Internal +12V Rails
Rail 1 +12V 62.5 A
Rail 2 +12V N/A
Rail 3 +12V N/A
Rail 4 +12V N/A
Rail 5 +12V N/A
Rail 6 +12V N/A
Max. Combined Output +12V 62.5 A
Modular Yes
Modularity Full Modular
SLI/CrossFire No
EPS 12V No
Motherboard Connector 24-pin
Connectors
1 x 12+4-pin PCIe
2 x 4+4-pin ATX 12V
1 x 4-pin FDD Power
4 x 4-pin Molex
4 x 6+2-pin PCIe
8 x SATA
Dimensions 150 x 140x 86 (WxHxD)
Package Type Retail
