MSI MPG B650 TOMAHAWK WI-FI AMD Socket AM5 Motherboard - Special Offer

Description

SPECIFICATION:
CPU AMD Socket AM5 for AMD Ryzen 7000 Series Desktop Processors
Chipset AMD B650
Memory 4 x DIMM, Max. 128GB, DDR5 5200MHz upto 6600MHz (OC)
Supports AMD EXTended Profiles for Overclocking (EXPO)
Onboard Graphics Outputs 1 x HDMI port
1 x DisplayPort
PCI Slots 2x PCI-E x16 slot
Support x16/ x4
1x PCI-E x1 slot
PCI_E1 PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 PCIe 4.0 supports up to x4 (From Chipset)
PCI_E3 PCIe 3.0 supports up to x1 (From Chipset)
Storage Total supports 3 x M.2 slots and 6 x SATA 6Gb/s ports
M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_3 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
Networking 1 x 2.5Gb Ethernet
WIFI 6E
Bluetooth
Audio Realtek® ALC4080 Codec
Connectivity DisplayPort 1.4
2.5G LAN Port
2x USB 2.0 Port
4x USB 3.2 Gen 1 5Gbps Type-A
Wi-Fi / Bluetooth Antenna
HD Audio Connectors
Flash BIOS Button
HDMI™ 2.1 Port
3x USB 3.2 Gen 2 10Gbps Type-A
USB 3.2 Gen 2x2 20Gbps Type-C
Optical S/PDIF OUT
Internal Ports 1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
6x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Tuning Controller connector(JDASH)
2x Addressable V2 RGB LED connector (JARGB_V2)
2x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0
2x USB 3.2 Gen1 Type A
1x USB 3.2 Gen2 Type C
Form Factor ATX - 243.84mmx304.8mm
Warranty Three Year Manufacturer Warranty
