Description
Designed with a native PCIe 12+4pin connector, the Toughpower GF3 series is compatible with Intel `s ATX 3.0 specification and is built for next-gen PCIe 5.0 graphics cards. It can pipe up to 600W of power to PCIe 5.0 graphics cards.
TOUGHPOWER GF3 AT A GLANCE:
PCIe Gen 5 ready, designed with native PCIe 12+4pin modular interface.
Compatible with Intel ATX 3.0 specification.
80 PLUS Gold Certified up to 90% efficiency.
135mm fluid bearing fan.
100% Premium quality 105°C Japanese capacitors.
< 30mV low ripple noise design.
TOUGHPOWER GF3 SPECIFICATIONS:
WATTS 1200W
MODEL TPD-1200AH3FCG
MAX. OUTPUT CAPACITY 1200W
COLOR Black
DIMENSION ( W / H / D ) 150mm(W) x 86mm(H) x 160mm(D)
WEIGHT 1.88 KG
PFC (POWER FACTOR CORRECTION) Active PFC
INPUT CURRENT 15.0A / 7.0A
INPUT FREQUENCY RANGE 50/60Hz
INPUT VOLTAGE 100V - 240V~
EFFICIENCY Meet 80 PLUS®Gold at 115Vac input
MTBF 100,000 hrs minimum
