Description
- Dual BIOS Intelligent Fan Controller
- Choosing the BIOS that fits your need: better overclocking or silent operation.
- Utilizing temperature detection from a smart chip, fans will start running when the GPU reaches - 60°C and shut down below 50°C.
- GPU Direct-Contact Copper Plate Triple Ring-Fan
- A large copper plate provides direct contact with the GPU while covering VRAM area to increase the heat transfer threshold to the max.
- The 3X90mm Ring-fan design improves the cooling performance.
- Back Plate Signature LED Color
- The metal back plate is extremely rigid to strengthen the card to prevent PCB bending.
- Showcasing a cool and elegant aesthetic, the icy blue LED lighting sets a high-class tone.
Specification Details
EAN CODE 4713436175957
Bus Standard PCIE 5.0 x16
Graphics Engine RX9060XT 16G-L/OC
Display Connectors 1 x HDMI 2.1b, 2 x DisplayPort 2.1a
Video Memory 16GB GDDR6
Form Factor ATX
Stream Processor 2048 Units
Cooler 2 Slot Triple Fan
Game Clock 2740 MHz (OC) / 2620 MHz (Silent)
Power Connector One 8-pin PCI Express Power Connector
Engine Clock Boost 3310 MHz (OC) / 3230 MHz (Silent)
OpenGL 4.6
DirectX® Support 12
Memory Speed 20.0 Gbps
Minimum System Power 550W
Memory Interface 128 bits
Card Dimension (mm) 310 x 100 x 40 mm
330 x 120 x 40 mm (with bracket)
Accessories Bundle Gaming Gear Intro Card
* `Game Clock` is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
* `Boost Clock` is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
