PHANTEKS Evolv Series X2 Case Tempered Glass Windows DRGB Matte White

Description

The Phanteks Evolv X2 is the perfect showcase for all your gaming hardware - at any angle! This case includes three crystal clear tempered glass panels, that wrap from the left of the case, around the front, and ends on the right side, giving it a see-through appearance. Enhancing this unique design, the Phanteks Evolv X2 boasts compatibility with hidden connector motherboards, perfect for building a super clean gaming PC. Additionally, the Phanteks Evolv X2 offers excellent support for the latest gaming hardware, with space for CPU coolers up to 170mm high and a GPU clearance of 380mm. What’s more, the Evolv X2 features an innovative vertical cooling layout, with space for a total of seven 120mm fans. Additionally, at the top of the Evolv X2 is a dedicated compartment to install a 360mm radiator. Unlike many other cases, Phanteks has incorporated the cooling fans into the structure of the Evolv X2, where they will sit perfectly flush with the case panels for a seamless aesthetic. Furthermore, with three colours to choose from, including Brushed Black, Silver White, and Black Gold, you can easily build a gaming PC to match your unique style.

Phanteks Evolv X2 Mid-Tower PC Case at a Glance:
Mid-tower PC case
Three sides of tempered glass panels offer a clean transparent aesthetic
Compatible with both MSI Project Zero and ASUS BTF motherboards
Vertical cooling design with space for up to seven 120mm fans
GPU clearance up to 380mm long and 178mm wide
Available in three colours Brushed Black, Silver White, and Black Gold

Can See Right Through You
The Phanteks Evolv X2 is the perfect case for displaying your gaming hardware from any angle. Boasting three tempered glass panels, that wraps the front and both sides of the case, giving the Evolv X2 a unique see-through design. This helps to create a super clean aesthetic, where all attention is focused on your gaming hardware.

To enhance this aesthetic, the Phanteks Evolv X2 offers phenomenal cable management, including full combability with MSI Project Zero, and ASUS BTF hidden connector motherboards. Additionally, the Evolv X2 features a large compartment behind the motherboard tray that offers ample space for storing excess wires out of sight, allowing you to minimise any visible cables in the main chamber of the case.

To enhance the visual appeal of the Phanteks Evolv X2, this case is available in a range of finishes. Most of the case features a matte finish, with brushed metal internal accent panels. The colour options available are Brushed Black, Silver White, and Black Gold.

Out of Sight Cooling
With its unique layout, the Phanteks Evolv X2 features an innovative vertical cooling design, where cool air is drawn in through the base and exhausted out the top. To do this, the Evolv X2 utilises three 120mm fans at the base of the case, perfect for intake. What’s more, the Phanteks Evolv X2 can be sat on any surface, including thick carpet, as the main structure of the case is raised up several centimetres by four feet, which are attached to a solid base plate.

Three more 120mm fans can be housed at the top of the case, with an additional mount also available on the rear panel which facilitates a 120mm fan. These fans will help to draw air up through the case to cool your components, then exhaust the warm air out the top. Additionally, the Phanteks Evolv X2 top panel conceals a dedicated chamber for housing a 360mm radiator.

Furthermore, the Phanteks Evolv X2 has a unique way of mounting cooling hardware, to further enhance aesthetics. Each fan mounting point is recessed into the chassis, as such they will sit perfectly flush with the surrounding panels. By mounting fans inside their own enclosures, there is less room for air to escape, ensuring more air will be channelled up through the case to maximise cooling performance.

There are multiple options for CPU cooling, with a dedicated chamber at the top of the case for easy installation of a radiator, perfect for AIO coolers. An added benefit of moving your cooling hardware to this compartment, is that the Evolv X2 offers better compatibility between your motherboard and AIO. Alternatively, if you prefer air cooling, with 170mm of clearance there is ample room to install a large tower CPU air cooler.

Hardware Options
A Phanteks Evolv X2 is an excellent platform on which to build a powerful gaming PC, as it offers excellent compatibility with the latest gaming hardware. In addition to facilitating hidden connector motherboards, this chassis supports Mini-ITX, Micro-ATX, ATX, and 280mm wide E-ATX. boards What’s more, with eight PCIe slots and 380mm clearance, you’ll have plenty of space for a powerful GPU.

The bottom of the chassis conceals several compartments, including a large PSU chamber that can facilitate power supplies up to 250mm long. The PSU chamber is hidden by a large door, which also covers the rear of the motherboard to help hide your cables. In its own separate compartment in front of the PSU chamber, there is a drive cage which easily hold a combination of 3.5`` HDDs and 2.5`` SSDs. The drive cage is accessed via a small panel which is separate to the main door used to conceal the PSU and cables.

Case Features
I/O position     Side
Side panel     with window
Cable Management     Yes
Filters included     Yes
Back Connect
Back Connect     Yes
Back-Connect Compatibility     ASUS BTF, MSI Project Zero
Colour
Primary Colour     White
Expansion Slots
Expansion slots / PCI slots     8
Lighting
Lighting / RGB     Yes
Compliance
Compliance Documents     PHANTEKS Evolv X2 Compliance and Safety
Drive Bays
2.5 inch internal drive bay     2
3.5 inch internal drive bay     2
Motherboard Support
Compatible Motherboard Formats     E-ATX, Mini-ATX, ATX, Micro-ATX
Max. Motherboard Format     E-ATX
Dimensions
Length / Depth     454 mm
Width     228 mm
Height     588 mm
Weight     14.2 kg
Additional Contents
Included fans     None
Radiator Support
Max. Radiator Compatibility     1x Triple (360 mm)
Materials
Materials     Steel
Case
Case Type     Mid Tower
Internal Dimensions
Max. CPU Cooler Height     170 mm
Max. GPU Length     380 mm
Max. PSU Length / Depth     250 mm
Power Supply
PSU Format     ATX
Power Supply Position     bottom
External Ports
USB 3.2 (external) Type C     1
USB 3.0 (external) Type A     2
Audio outputs & inputs     1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
Fan Support
120 mm fans     7
