NZXT C Series 1200W Black 80+ Gold PCIE 5.1 Power Supply/PSU ATX3.1

Description

Meet The Pinnacle of Performance
The NZXT C Series Gold ATX 3.1 power supplies deliver exceptional performance with minimal noise, designed to meet the demands of high-end GPUs and CPUs. Compliant with the ATX 3.1 standard, these PSUs ensure stability, efficiency, and power spike resistance. Featuring a durable 12V-2x6 connector that supplies up to 600 watts for NVIDIA GeForce RTX 40 Series graphics cards, they are built for demanding setups. The 135mm fluid dynamic bearing fan operates silently under 50% load thanks to Zero Fan Mode, while premium Japanese capacitors provide reliable power delivery with minimal ripple noise. With a fully modular design for reduced clutter and improved airflow, along with a compact form factor for better cable management, the NZXT C Series is an ideal choice for gamers and PC builders seeking performance and efficiency.

Efficiency Meets Excellence
Experience top-tier performance with NZXT`s ATX 3.1 compliant PSUs, designed for high efficiency, whisper-quiet operation, and premium construction. Perfect for gamers and enthusiasts seeking reliability.
Tech Specs

Output Connectors
24-pin ATX Power Cable:1
4+4-pin CPU Power Cable:1
8-pin CPU Power Cable:1
6+2-pin PCIe Power Cable:3
16-pin (12+4) 12V-2x6 PCIe Cable:1
SATA Cable:12
Peripherals Cable:4

Cable Specs

24-pin ATX Power Cable:600mm with nylon sleeving

4+4-pin CPU Power Cable:700mm with nylon sleeving

8-pin CPU Power Cable:700mm with nylon sleeving

6+2-pin PCIe Power Cable:650mm with nylon sleeving

16-pin (12+4) 12V-2x6 PCIe Cable:650mm with nylon sleeving

SATA Cable:500 + 150mm

Peripherals Cable:500 + 150mm

AC Input Rating
100 - 240Vac:14A 50Hz-60Hz
200 - 240Vac:7A 50Hz-60Hz (China & South Korea)
DC Output Rating
3.3V / +5V:22A (120W)
12V:100A (1200W)
5Vsb:3A (15W)
Total:1200W

Energy Efficiency
Rating:80 Plus Gold
10% loading:85% @115Vac
20% loading:90.1% @115Vac
50% loading:91.6% @115Vac
100% loading:88.7% @115Vac

Electrical Features
PF Correction:Active @0.99
Protections:OVP (Overvoltage Protection) / UVP (Undervoltage Protection) / SCP (Short Circuit Protection) / OTP (Over Temperature Protection) / OPP (Overpower Protection) / OCP (Overcurrent
Protection) /

Fan Specs
Dimensions:135 x 135 x 25 mm
Speed:2300 ± 10% RPM
Airflow:93.02 CFM (Min.)
Noise:44.5 dBA max
Bearing:Fluid Dynamic Bearing (FDB)

Operation
MTBF:100,000 hours
Temperature:0 - 50 °C
Dimensions
Width:150 mm
Height:86 mm
Depth:160 mm

General
Material(s):Steel, PCB and Plastic
Compliance Standard:ATX12V v3.1 / EPS12V v2.92
Regulation & Certification:FCC, Canada, CE, CB(IEC 62368-1), UKCA, CCC, BSMI, BIS, RCM, UAE, TUV, cTUVus, KC, CP65
Warranty:10 Years
