MSI MPG Z490 CARBON EK X with custom designed EK Liquid Cooled CPU Block

Description

Description
The MPG Z490 CARBON EK X comes with a custom-designed EK cooling solution, a monoblock that aesthetically blends with the motherboard. The iconic carbon fiber and matching engraved design shows its refined quality and distinctive looks. To unleash the high performing for 10th gen Intel core processors, the custom-designed EK cooling solution that offers pristine cooling for both the CPU and VRM power delivery section is used to prevent thermal throttling, allowing gamers to sustain heavy gaming loadings without the noisy environment. It’s ready for everything!

- CPU
CPU Socket Socket 1200
CPU Brand Intel
Installed Processors (Max) 0 (1)
Supported Processor Manufacturer Intel
Supported Processors 10th Gen Intel Core and Pentium Gold / Celeron processors
64-bit Support Yes
Socket LGA1200

- Rear Panel I/O Ports
USB Ports 4 x USB 3.12 x USB 2.0
DisplayPorts 1 x DisplayPort
HDMI Port 1 x HDMI
Keyboard/Mouse Combo Port 1 x PS/2
RJ-45 Ports 1 x RJ-45
Audio Line In Ports 1 x 3.5mm Jack
Audio Line Out Ports 3 x 3.5mm Jacks
Microphone In Port 1 x 3.5mm Jack
S/PDIF Port 1 x S/PDIF Optical Out
Antenna Connector(s) 2 x SMA Antennas

- Internal I/O Connectors
SATA Connectors 6 x SATA III
USB Connectors 1 x USB 3.1 Type-C header (supports 1 port)1 x USB 3.0 headers (supports 2 ports)2 x USB 2.0 headers (supports 4 ports)
Cooling Fan Support 1 x CPU fan header1 x Water Pump fan header6 x System fan headers
Thunderbolt Port(s) 1 x TBT header
Serial Connectors 1 x COM header
Chassis Intrusion Connector 1 x Chassis Intrusion header
TPM Header 1 x TPM header
Power Connector Port 1 x 20 4-pin ATX1 x 4 4-pin EPS1 x 4-pin EPS
Other Connectors 1 x M.2, Socket 3, M Key (Type 2242/2260/2280/22110)1 x M.2, Socket 3, M Key (Type 2242/2260/2280)2 x 3-pin ARGB LED headers1 x 4-pin RGB LED header1 x 3-pin CORSAIR LED header1 x RTD3 header

- Memory
Memory Bus Speed Up to 5000 MHz
Memory Type DDR4
Maximum RAM 128 GB
Memory Slot 4 x DIMM
