Description
Full-Coverage Micro-Mesh
Serves as a low pressure and low resistance air intake for optimal temps & noise levels.
Patent-Pending Louvered Blade Ventilation
Reduces exhaust impedance by slicing through hot air while reinforcing chassis rigidity
Cold-Floor Cooling
Keeps your graphics card comfortably cool with direct airflow from up to 3x 120mm extra thick fans
Structural PSU Canopy
Ideally placed for hassle-free cable management with meticulously placed tie-down points wish included velcro straps both inside and outside the chassis
Disciplined Multi-Dimensional Design
Seamlessly blends premium materials such as steel and tempered glass with exquisite craftsmanship, resulting in simple, soft, perfect forms across every curve inside the case
Additional Contents
Fans Included No
Included fans None
Lighting
Lighting / RGB No
Back Connect
Back Connect No
Fan Support
Case Fan Support (Side) 120mm Fan (3x)
Case Fan Support (Rear) 120mm Fan (1x)
Max. Number of Fans 10
Case Fan Support (Bottom) 120mm Fan (3x)
Case Fan Support (Front) 120mm Fan (3x), 140mm Fan (3x)
120 mm fans 10
140 mm fans 3
Case Features
I/O position Top
Side panel with mesh
Vertical GPU Mount No
Adjustable Vertical GPU Bracket No
Front door No
Cable Management Yes
Filters Included Yes
Filter Position Bottom
Noise dampening No
Mainboard slide / tray No
Transport System No
Colour
Primary Colour Black
Radiator Support
Radiator/AIO Support (Front) 360mm Radiator
Max. Radiator Compatibility 360
Radiator/AIO Support (Rear) 120mm Radiator
Radiator/AIO Support (Side) 360mm Radiator
Power Supply
PSU included No
PSU Format ATX
Power Supply Position rear top
Mounting
Case VESA Mountable No
Internal Monitor Mount No
Case
Case Type Mid Tower
Internal Dimensions
Max. CPU Cooler Height 170 mm
Max. GPU Length 430 mm
Max. GPU Width 160 mm
Max. PSU Length / Depth 223 mm
Inner Volume 63 l
Dimensions
Length / Depth 510 mm
Width 255 mm
Height 485 mm
Drive Bays
Max. 2.5 Inch Drives 2
Max. 3.5 Inch Drives 1
Max. 5.25 Inch Drives 0
Hot swap drive bays No
Materials
Materials ABS, Steel
Features
Housing Feedthrough No
Display
Display Included No
Motherboard Support
Max. Motherboard Format E-ATX
Compatible Motherboard Formats E-ATX, ATX, Micro-ATX, Mini-ITX
Product Series
Product Series/Family X50
Fan Header
Fan Controller / Fan Hub No
Expansion Slots
Expansion slots / PCI slots 7
External Ports
Front I/O – USB Type C Ports Total 1
Front I/O – USB Type A Ports Total 2
USB 3.2 (external) Type C 1
USB 3.0 (external) Type A 2
Audio outputs & inputs 1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
