Description
Motherboard B760 GAMING X s1700 4DDR5 DP/HDMI ATXGIGABYTE
Model: B760 GAMING X
CPU socket: LGA1700
Processor family : Intel Core i3
Integrated CPU: No
Chipset manufacturer: Intel
Chipset type: Intel B760 Express Chipset
Memory type : DDR5
Number of DDR5 slots: 4
Memory bus frequency : 7600 MHz
Expansion slots : 2 x PCIe 3.0 x 16
RAID: Yes
Detailed data on disk/drive interfaces: Processor: 1 x M.2 connector (slot 3, Key M, support for 22110/2280 PCIe 4.0 x4/x2 SSD) (M2A_CPU) Chipset: 2 M.2 connectors (slot 3, Key M, support for SSD type 22110/2280 PCIe 4.0 x4/x2) (M2P_SB, M2M_SB), 4 SATA 6 Gb/s connectors
Graphics: Integrated graphics processor - support for Intel HD graphics: (Graphics specifications may vary depending on processor support.) DisplayPort, supporting a maximum resolution of 4096x2304 at 60 Hz - Support for DisplayPort version 1.2 and HDCP 2.3, HDMI port, supporting a maximum resolution of 4096x2160 at 60 Hz - Support for HDMI 2.0 and HDCP 2.3.
Sound card: Realtek Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel, S/PDIF Out
Network interface : Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
FireWire (IEEE 1394): No
COM connector / port: Yes
LPT connector / port: No
External connectors : 1 x USB 3.0
Onboard connectors : 1 x 8pin 12V power
Special functions: Support for GIGABYTE Control Center (GCC), Q-Flash support, Q-Flash Plus support
BIOS: 1 x 256 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form factor: ATX
Dimensions: 30.5 x 24.4 cm
Supported operating systems : Windows 10
Software: Norton Internet Security (OEM version), LAN bandwidth management software
EAN: 4719331851989
Manufacturer: Gigabyte
