Description
Ascension Unbound
Gliding across its brushed metal etching, the Gigabyte B860M AORUS ELITE Wi-Fi 6E stands out with sharp, minimalist lines that speak to those who demand both high-end performance and an impressive visual presence. Powered by the B860 chipset, it drives fast speeds and smooth multitasking, giving you everything you need for demanding games and serious workloads. Beneath its expertly crafted thermal armor, cutting-edge connectivity flows, ready for whatever you throw at it, from intense gaming sessions to large-scale projects. Every inch of this motherboard embodies AORUS excellence, made for those who want their build to run hard and look even better.
Core Specifications
Edition B860M AORUS ELITE WIFI6E
Form Factor MicroATX
CPU Socket 1851
Chipset Intel B860
RAM Memory Support
Memory Type DDR5
Memory Channel Dual (2)
Memory Type (ECC) Non-ECC
Memory Type (R/U) UDIMM (Unbuffered)
Memory Speed (Mhz)
Max. Memory Capacity 256GB
Audio
Audio 7.1 Channel HD Audio
Graphics Support
Primary GPU Interface PCIe 5.0 (x16)
NVIDIA SLI Support N/A
AMD CrossFire Support N/A
Integrated Graphics Discrete GPU Required for Graphics Output
On-Board Graphics Connectors
DisplayPort 2.1
HDMI 1.4
HDMI 2.1
USB 4.0
Internal Connectivity
Expansion Slots
1 x M.2, 22-80, PCIe Gen4x4
1 x M.2, 22-80, PCIe Gen5x4
1 x M.2, 22-80/110, PCIe Gen4x4
1 x PCIe 4.0 x16
1 x PCIe 5.0 x16
4 x SATA 6GB/s
SATA Support N/A
RAID Support via
Storage Mode Support
RAID 0
RAID 1
RAID 10
RAID 5
Internal I/O
1 x 24-pin (Power)
1 x 8-pin (Power)
3 x Addressable Gen 2 Header
1 x Clear CMOS jumper
1 x CPU Fan Connector
1 x CPU Water Pump/Fan Connector
1 x Front Panel Audio Header
1 x Front Panel Connector
3 x M.2
1 x Power button
1 x Q-Flash Plus Button
1 x Reset Button
1 x RGB Header
4 x SATA III - 6Gb/s
3 x System Fan header
1 x System Fan/Water Pump Header
2 x Thunderbolt AIC Connector
1 x TPM Header
2 x USB 2.0
1 x USB 3.2 Gen1 Head
