MasterBox 520 is the ideal chassis for satisfying the needs of both novice and experienced gamers.

MASTERBOX 520 AT A GLANCE
Tempered Glass Front Panel
Three CF120 ARGB Fans Included
ARGB Controller Included
Removable Top Panel
Screwless + Tool-Free TG Side Panel
Removable HDD cage
MASTERBOX 520 SPECIFICATION
Materials - Exterior	Steel, ABS Plastic, Tempered Glass
Materials - Left Side Panel	Tempered Glass
Dimensions (L x W x H)	502 x 210 x 498mm (Incl. Protrusions), 443 x 210 x 498mm (Body Size)
Volume	50L
Motherboard Support	Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12`` x 10.7`` motherboards, may impact cable management feature)
Expansion Slots	7
3.5`` Drive Bays	2
2.5`` Drive Bays	3
I/O Panel - USB Ports	1x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button
Included Accessories	ARGB Fans Hub
Pre-installed Fans - Front	3x CF120 ARGB
Pre-installed Fans - Rear	1x MasterFan Lite 120
Fan Support - Top	3x 120mm, 2x 140mm
Fan Support - Front	3x 120mm, 2x 140mm
Fan Support - Rear	1x 120mm
Radiator Support - Top	120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm)
Radiator Support - Front	120mm, 140mm, 240mm, 280mm, 360mm
Radiator Support - Rear	120mm
Clearance - CPU Cooler	165mm / 6.49``
Clearance - PSU	200mm, (Recommended up to 170mm)
Clearance - GFX	410mm / 16.14``
Power Supply Support	Bottom Mount, ATX
Warranty	2 years
